The
KTM 390 Adventure is inspired from the Dakar winning KTM-450 Rally, deriving
much from KTM’s rich legacy in Rally Racing in terms of chassis, profiling
& several specs such as a larger fuel tank, ergonomics & wind
protection to ensure a steady, safe & easy ride on any surface that is on offer.
The
390 Adventure is purpose built for adventure travel and features a lightweight
Trellis frame chassis, a long travel suspension by WP with 170mm of wheel
travel in the front and 177mm of wheel travel in the rear, knobby tyres by
Metzeller, high ground clearance of 200mm, long wheelbase, extendable
windshield and a protective bash plate for the engine.
The
most differentiating aspect of the 390 Adventure is that it comes packed with a
set of first in class electronics or rider aids which have been so far limited
only to the superbikes in the liter class. The Electronic Control Unit or ECU
controls a host of electronic aids like the lean angle sensitive Motorcycle
Traction Control
(MTC)
which allows for better traction on dirt and loose gravel surfaces, Cornering
ABS which provides for a safer and sharper ride through the twisties, Offroad
ABS for better steering on low traction surfaces, Quickshifter+ for smooth
clutchless up and down shifting and KTM MY RIDE smartphone connectivity for
calls, music and an optional turn-by-turn navigation, all nicely displayed and
relayed by the full-color TFT display. These aids work seamlessly to ensure a
feeling of optimal control and come into play in the trickiest of situations.
The
390 Adventure builds on the versatility of the KTM 390 Duke Engine - a
state-of-the-art DOHC single cylinder head technology - derived from KTM´s
high-performance race models and electronics such as EFI and ride by wire
resulting in class leading 43 Hp of Power and 37 Nm of Torque
Technical
Specifications :
Engine Type
|
Single
Cylinder, 4-stroke, 4 V DOHC Engine
|
Cooling
|
Liquid
Cooling
|
Displacement
|
373.2cc
|
Fuel
System
|
Bosch
EFI
|
Bore/Stroke
|
89/60
mm
|
Power
|
32
kw(43 HP) @ 9000 RPM
|
Torque
|
37Nm
@ 7000 RPM
|
Compression
Ratio
|
12.6:1
|
Transmission
|
6
Gears
|
Lubrication
|
Wet
Sump
|
Clutch
|
PASC
Slipper Clutch, Mechanically Operated
|
Frame
|
Steel
Trellis Frame, Powder-coated
|
Subframe
|
Steel
Trellis Frame, Powder-coated
|
Front
Suspension
|
WP
Apex 43mm Upside down Suspension
|
Rear
Suspension
|
WP
Apex Shock Absorber
|
Suspension
Travel Front/Rear
|
170mm/177mm
|
Front
Brake
|
Single
Piston, Radially mounted calliper, Brake disc of 320 mm
|
Rear
Brake
|
Double
Piston, Floating Calliper, Brake Disc of 230 mm
|
Wheels
Front/Rear
|
Cast
Aluminium wheels 19" Front - 17" Rear
|
Tires
Front/Rear
|
100/90(Front)/130/80
(Rear) - Metzeller Tourance Tyres
|
ABS
|
Bosche
9.1 MP Twin Channel Cornering ABS
|
Traction
Control
|
Lean
sensitive Motorcycle Traction Control
|
Quickshifter
+
|
Yes
|
KTM
My Ride
|
Bluetooth
Connectivity with Navigation
|
Battery
|
12
V 8 AH
|
Headlight
|
LED
Type, Low Beam 1.7A,24W High Beam 2.6A, 36W
|
Dimensions
(LXWXH)
|
2154x900x1400
mm
|
Seat
Height
|
855mm
|
Wheelbase
|
1430
mm
|
Ground
Clearance
|
200
mm
|
Fuel
Tank Capacity
|
14.5
L
|
Dry
Weight
|
162
Kg
|
