Chassis
The Hypermotard 698 Mono is compact and lightweight, with a curb weight of 151 kg without fuel. A result obtained thanks to solutions such as the trellis frame with differentiated sections and thicknesses weighing only 7.2 kg, capable of combining strength with rigidity and lightness, to the cast rims (-0.5 kg compared to similar spoked wheels), to the brake discs with aluminium flange (-17% compared to a steel unit) and to the lightweight Marzocchi fork, fully adjustable and equipped with external adjusters, with upside-down front forks and 45 mm aluminium sliders, weighing only 8.1 kg.
The rims are fitted with Pirelli Diablo Rosso IV tyres, measuring 120/70 ZR 17 at the front and 160/60 ZR 17 at the rear.The front braking system relies on a single 330 mm disc developed specifically by Brembo for the Hypermotard 698 Mono, with Brembo M4.32 radial caliper. At the rear there is a single 240 mm disc, also with a dedicated design.
The riding position is designed to guarantee maximum control in sporty riding, supporting both traditional riding with the leg stretched towards the ground and that with the knee on the ground. The variable section handlebar determines a dominant position, favouring body movements.
Engine
The Ducati Hypermotard 698 Mono debuts the new Superquadro Mono, the latest addition to the Borgo Panigale engines which presents itself as a new performance benchmark among single-cylinder road bikes.
Powerful, light and compact, it comes from the most powerful and refined twin-cylinder ever created by Ducati: the 1,285 cc Superquadro of the 1299 Panigale. It retains the 116 mm bore of that engine, a record value for a road single-cylinder, combined with a stroke of 62.4 mm for a displacement of 659 cc.
The box-in-box piston, the titanium intake valves, the aluminium cylinder liner, the piston pin equipped with DLC coating and naturally Desmodromic distribution make the Superquadro Mono capable of revving at speeds normally reserved only for racing single cylinders (the limiter is set at 10,250 rpm) and delivers a maximum power of 77.5 hp at 9,750 rpm.
Furthermore, thanks to the Termignoni racing exhaust, in track configuration the power increases by 7 horsepower reaching the incredible value of 84.5 hp, another record for a single cylinder.
